Meet the New X4
WiFi Connection
Capacitive Touch Screen
Powerful Processor
CoreXY
Advanced Industrial 3D Printing Solutions
Zaxe X4 offers state-of-the-art industrial 3D printing in a compact design, featuring the latest technology to elevate your printing experience.
...*Excl. VAT
Order Now
Request a Quote
High-Performance Printhead
The advanced printhead in Zaxe X4 ensures optimal productivity with minimal risk of clogging, extending the device's service life and delivering consistent performance over time.
Enhanced Automatic Calibration
Zaxe X4's fully automatic calibration system removes the guesswork, reducing errors and saving time, even for novice users.
Carbon Filtration
Environmentally friendly and reliable, Zaxe X4 is equipped with carbon filters designed to prevent the release of odors and harmful micro-particles, ensuring a safer printing environment.
Colorful Guiding LEDs
LED modules interact with users by illuminating the states of the functions. They give you feedback on printing phases so you always know the step you are on.
High-Speed CoreXY Mechanical System
Experience superior 3D printing performance with Zaxe X4's innovative CoreXY Mechanical System, providing the speed, precision, and consistency needed to enhance your production efficiency.
Robust Aluminum Frame
Vibration during high-speed printing sessions can decrease print quality. Zaxe X4 has a body that is manufactured in one single piece. The stable frame reduces vibrations during intense printing sessions which guarantees better print quality every time you use it.
Powerful Zaxe Electronics
X4's backbone is the new xBoard. This new motherboard comes equipped with a 32-bit processor and 5 drivers and will be the base of operations for your X4.
Versatile Printing Platform
The flexible, magnetic, and textured printing table of Zaxe X4 allows for easy removal of prints without the need for tools, offering both smooth and textured surfaces to suit various printing needs.
Meet Our Printing Table
Technical Specifications
Printing Properties | |
Nozzle Diameter | 0,25/0,4/0,5/0,6/0,8 mm |
Layer Resolution | 50 - 800 Micron |
Bed Material | Double Sided Flexible PEI Sheet |
Bed Max Temp. | 120°C |
Extruder Max Temp. | 350°C |
3D Printer Properties | |
Dimensions | 424 x 524 x 539 mm |
Build Volume | 250 x 250 x 260 mm |
Print Area | Closed, Heat Insulated |
User Panel | 7" Color Touch Screen |
Printhead | Zaxe Print Head |
Calibration | Hands-Free Fully Automatic |
Camera | Yes / AI Camera |
Power Outage Protection | Yes |
Filament Sensor | Yes |
Filter | Carbon Filter |
Software & Connectivity | |
Software | xDesktop |
Supported File Types | .stl, .obj, .step, .stp, .amf, .3mf, .x3d |
Connections | Wi-Fi, Ethernet, USB, Flash Disk |
Material | |
Material Feed | Filament Spool |
Filament Diameter | 1,75 mm |
Supported Materials | PLA, ABS, PETG, TPU, PLA-CF, PPS-CF, PET-CF, PA-CF, PA-GF, PC-ABS |
